Thursday 12 September 2013

DateTime object Issue in BusinessRuleGroup Component in BPMV7.5



Scenario:-

To explain date time object issue I  had taken this simple scenario.

Scenario aims to calculate “OrderDeliveryFromDate “,”OrderShippingDate” from order details by applying below business rules.

  • If shift = 3 then set  TmpHours = 06:00:00.
  •  If shift = 4 then set TmpHours =  20:00:00.
  •  Else = set TmpHours = 15:00:00.
  •  Add TmpHours to “OrderCreationDate” from input.
  •  Add “OrderCreationDate” to “OrderDeliveryFromDate” in Output.
  • Add “7 days” to “OrderCreationDate” in input.
  •   Add “OrderCreationDate” to “OrderShippingDate” in Output.

Business Object:-





Interface:-



Business Rules implementation:-



RuleLogic Name:- getOrderDateBRLogicIssue



Note:-Rule Templates are not used


Test Case:-

Used below values  for Testing

Input:-

  Shift=3

  OrderCreationDate =2013-09-03T00:00:00.000

Expected Result:-



OrderDeliveryFromDate=2013-09-03T20:00:00.000

OrderShippingDate =2013-09-10T20:00:00.000

Output:-

OrderDeliveryFromDate=2013-09-10T20:00:00.000

OrderShippingDate =2013-09-10T20:00:00.000

Problem:-


If any calculations performed on “OrderShippingDate “,It  effected  on OrderDeliveryFromDate”  value  .



TestCase1 Input:-




TestCase1 Output:-




Resolving Steps:-


To resolve issue created a temporary variable as anytype in business rules (tempOrderCreationDate ) and saved the copy of  “OrderCreationDate”  value  in tempOrderCreationDate using clone() method.(As shown below)



Business Rules implementation:-

RuleLogic Name:- getOrderDateBRLogic Solution




Input:-


  Shift=3

  OrderCreationDate =2013-09-03T00:00:00.000

Expected Result:-

OrderDeliveryFromDate=2013-09-03T20:00:00.000

OrderShippingDate =2013-09-10T20:00:00.000

Output:-

OrderDeliveryFromDate=2013-09-03T20:00:00.000

OrderShippingDate =2013-09-10T20:00:00.000

TestCase2 Input:-




TestCase2 Output:--



 DownLoad the PI from below link
Please post any issues/querys related to BPM,WODM and DATAPOWER  to "mdondetimss@gmail.com"
